ASME Life Cycle Test Machine for Cookware Durability Testing

This machine evaluates the lifespan of pull-out tubes, showerhead buttons, and water outlet swing to assess product quality.

ASME A112.18.1-2005; CSA B125.1-05; GB18145; EN817

• Test samples: 4 sets (1 pull-up water divider, 1 button set, 2 swing sets)
• Lifting function parameters:
  • Water divider function: 0-20mm adjustable
  • Speed range: 0-20 cycles/min adjustable
  • Action sequence: Cylinder clamps/pulls → releases → returns (1 cycle)
• Button function parameters:
  • Normal water supply function
  • Pressing speed: 5-30 times per minute
• Swing function parameters:
  • 2 workstations for left/right swing
  • Angle: Adjustable ±90°
  • Speed: 5-30 cycles per minute
• Frequency setting: 1 to 99,999,999 cycles
• Control: PLC system
• Operation: 7" color touch screen
• Power: 380V 50HZ
• Air source: 6kg
• Material: SUS304 stainless steel
• Water supply: American standard, dynamic pressure 0.3-0.4Mpa

• Workstation 1: Water introduction → cylinder lowering → head grasping/lifting → release → water circuit disconnection (1 cycle)
• Workstation 2: Shower head switching life test with 360° adjustable cylinders
• Workstations 3 & 4: Torque sensor for rotation with adjustable force, angle, and height
